PC TC PRO, 1/2x9 - 70 W Fluorescent Electronic Gear

Unavailable

CCC CCC
CE CE
EAC EAC
EL EL
ENEC ENEC
GOST GOST
RCM RCM
RoHs RoHs
AC voltage range 198 – 264 V
DC voltage range 176 – 280 V (lamp start ≥ 198 V DC)
Mains frequency 0 / 50 / 60 Hz
Overvoltage protection 320 V AC, 1 h
▼ see full specification ▼

Ask for product Description / FAQ / Warranty Data sheet

Score

rate product

Description / FAQ Warranty

Tridonic - parametry
	CCC
	CE
	EAC
	EL
	ENEC
	GOST
	RCM
	RoHs
AC voltage range	198 – 264 V
DC voltage range	176 – 280 V (lamp start ≥ 198 V DC)
Mains frequency	0 / 50 / 60 Hz
Overvoltage protection	320 V AC, 1 h
Type of protection	IP20
Mains voltage range	220 – 240 V
Defined warm start	≤ 1.6 s
Operating frequency	≥ 40 kHz

CELMA Energy Efficiency Index A2 BAT / A2
Nominal life-time up to 50,000 h (at ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h)
Large temperature range (for values see table)
Devices can operate either 1 or 2 lamps
Intelligent Voltage Guard (overvoltage indication and undervoltage shutdown)
Constant luminous flux irrespective of fluctuations in mains voltage
For luminaires of protection class I and protection class II
Automatic start after replacement of defective lamps
Safety shutdown of defective lamps and at end of lamp life (EOL 2)
For emergency lighting systems as per EN 50172
For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
Temperature protection as per EN 61347-2-3 C5e
