DALI-RM/S 4x10 A LED Power Supplies

Product code: 72803
Price € 182,33 incl. VAT
€ 182,33 netto
szt.
szt.
  • Weight per pc. 0.46 kg
  • Packaging, carton 1 pc(s).
  • Inputs 1
  • Output, relay 4 (make contact)
  • CE CE
  • DALI DALI
  • EAC EAC
  • RCM RCM
  • RoHs RoHs
  • Rated supply voltage 230 – 240 V
  • Mains frequency 50 / 60 Hz
  • Ambient temperature ta 0 ... +50 °C
  • ▼ see full specification ▼
Ask for product Description / FAQ / Warranty Data sheet

Score

* * * * *

rate product

1 variant available

DALI-RM/S 4x10A
DALI-RM/S 4x10A
Karta produktu PDF
Product code: 72803 Weight per pc.: 0.46 kg Packaging, carton: 1 pc(s). Inputs: 1 Output, relay: 4 (make contact)
€ 182,33 € 182,33 ex. VAT
szt.
szt.
Weight per pc. 0.46 kg
Packaging, carton 1 pc(s).
Inputs 1
Output, relay 4 (make contact)

Tridonic - parametry
tick CE
tick DALI
tick EAC
tick RCM
tick RoHs
Rated supply voltage 230 – 240 V
Mains frequency 50 / 60 Hz
Ambient temperature ta 0 ... +50 °C
Storage temperature ts -20 ... +70 °C
Type of protection IP20
Power < 2 W
Humidity(1) 5 % ... max. 85 %

  • Switching of 4 independent and potential free contacts via DALI
  • Max. switching current per contact: 10 A at ohmic load (cos Φ = 1)
  • 1 DALI address per switching contact
  • For installation in switching cabinets
  • Status LED for indicating the operating status
  • Test switch for installation test
  • 5-year guarantee
