Metal halide lamp MASTERColour CDM-Rm Mini Metal Halide Lamps GX10 / MR16

Philips CDM-Rm Mini 20W/830 GX10 MR16 10D

Price € 46,19 € 46,19 ex. VAT

See variants (3)

Ask for product Description / FAQ / Warranty

Score

rate product

Select your product from the 3

CDM-Rm Mini 20W/830 GX10 MR16 10D

Karta produktu PDF

Electrico24 code: 58179 | Philips code: 8718291202745 Cap-Base: GX10 Bulb: MR16 [2inch/50mm] Color Code: 830 [CCT of 3000K] Color Temperature: 3000 K LLMF - end nominal lifetime: 70 % Dimmable: No Energy Efficiency Label (EEL): A Energy consumption kWh/1000h: 20 kWh Switching cycle: 1350X Diameter D: 50 (nom), 51 (max) mm see more »

Overall Length C: 62.75 (nom), 65.4 (max) mm Full product code: 928191005331 Full product name: MASTERColour CDM-Rm Mini 20W/830 GX10 MR16 10D Order code: 928191005331 Order product name: CDM-Rm Mini 20W/830 GX10 MR16 10D Packing configuration: 12 Pieces per pack: 1 Bar code on outerbox - EAN3: 8718291202752 Bar code on pack - EAN1: 8718291202745 Packs per outerbox: 12 Logistic code(s) - 12NC: 928191005331 Net weight per piece: 0.047 kg Warm-up Time to 60% Light Outp: 120 s Beam Angle: 10 D Luminous Intensity: 13500 cd Luminous flux in 90° cone: 950 Lm Lamp Wattage: 20 W Operating Position: any [Any or Universal (U)] Beam Angle Technical: 7.5 (min), 10 (nom), 12.5 (max) D Color Rendering Index: 81 (min), 84 (nom) Ra8 Overall Length Rim C1: 60.9 (max) mm ILCOS code: MRS/UB-20/830-H-GX10-51/54.5/10 Life to 50% failures: 15000 hr Color Temperature Technical: 3000 K Mercury (Hg) Content: 3.5 mg Chromaticity Coordinate X: 0.440 - Chromaticity Coordinate Y: 0.400 - Lamp Wattage EL 25°C, Rated: 20.0 W Lamp Voltage: 93 V Damage Factor D/fc: 0.4 (max) - Life to 20% failures: 12000 hr Life to 5% failures: 9000 hr System Power EL: 23.5 W Ignition Time: 30 (max) s Lamp Current EL: 0.215 A Re-ignition Time [min]: 15 (max) min Run-up time 90%: 3 (max) min Reference Length A: 59 (max) mm Life to 10% failures: 10000 hr Design Mean Lumens EL: 850 Lm PET (NIOSH): 8 (min) h500lx Lamp Wattage EL: 20 W Forward Luminous Output: 945 (min), 1050 (nom) Lm Forward Lum Maintenance 2000h: 92 % Forward Luminous Efficacy: 53 Lm/W Forward Lum Maintenance 4000h: 85 % Forward Lum Maintenance 8000h: 78 % Forward Lum Maintenance 12000h: 75 % Forward Lum Maintenance 15000h: 70 % Reflector Neck Temperature: 215 (max) C « hide more

€ 46,19 € 46,19 ex. VAT

CDM-Rm Mini 20W/830 GX10 MR16 25D

Karta produktu PDF

Electrico24 code: 58180 | Philips code: 8718291203018 Cap-Base: GX10 Bulb: MR16 [2inch/50mm] Color Code: 830 [CCT of 3000K] Color Temperature: 3000 K LLMF - end nominal lifetime: 70 % Dimmable: No Energy Efficiency Label (EEL): A Energy consumption kWh/1000h: 22 kWh Switching cycle: 1350X Diameter D: 50 (nom), 51 (max) mm see more »

Overall Length C: 62.75 (nom), 65.4 (max) mm Full product code: 928191105331 Full product name: MASTERColour CDM-Rm Mini 20W/830 GX10 MR16 25D Order code: 928191105331 Order product name: CDM-Rm Mini 20W/830 GX10 MR16 25D Packing configuration: 12 Pieces per pack: 1 Bar code on outerbox - EAN3: 8718291203025 Bar code on pack - EAN1: 8718291203018 Packs per outerbox: 12 Logistic code(s) - 12NC: 928191105331 Net weight per piece: 0.047 kg Warm-up Time to 60% Light Outp: 120 s Beam Angle: 25 D Luminous Intensity: 4500 cd Luminous flux in 90° cone: 950 Lm Lamp Wattage: 20 W Operating Position: any [Any or Universal (U)] Beam Angle Technical: 16.5 (min), 22 (nom), 27.5 (max) D Color Rendering Index: 81 (min), 84 (nom) Ra8 Overall Length Rim C1: 60.9 (max) mm ILCOS code: MRS/UB-20/830-H-GX10-51/54.5/25 Life to 50% failures: 15000 hr Color Temperature Technical: 3000 K Mercury (Hg) Content: 3.5 mg Chromaticity Coordinate X: 0.440 - Chromaticity Coordinate Y: 0.400 - Lamp Wattage EL 25°C, Rated: 20.0 W Lamp Voltage: 93 V Damage Factor D/fc: 0.4 (max) - Life to 20% failures: 12000 hr Life to 5% failures: 9000 hr System Power EL: 23.5 W Ignition Time: 30 (max) s Lamp Current EL: 0.215 A Re-ignition Time [min]: 15 (max) min Run-up time 90%: 3 (max) min Reference Length A: 59 (max) mm Life to 10% failures: 10000 hr Design Mean Lumens EL: 850 Lm PET (NIOSH): 8 (min) h500lx Lamp Wattage EL: 20 W Forward Luminous Output: 945 (min), 1050 (nom) Lm Forward Lum Maintenance 2000h: 92 % Forward Luminous Efficacy: 53 Lm/W Forward Lum Maintenance 4000h: 85 % Forward Lum Maintenance 8000h: 78 % Forward Lum Maintenance 12000h: 75 % Forward Lum Maintenance 15000h: 70 % Reflector Neck Temperature: 215 (max) C « hide more

€ 46,19 € 46,19 ex. VAT

CDM-Rm Mini 20W/830 GX10 MR16 40D

Karta produktu PDF

Electrico24 code: 58181 | Philips code: 8718291203032 Cap-Base: GX10 Bulb: MR16 [2inch/50mm] Color Code: 830 [CCT of 3000K] Color Temperature: 3000 K LLMF - end nominal lifetime: 70 % Dimmable: No Energy Efficiency Label (EEL): A Energy consumption kWh/1000h: 22 kWh Switching cycle: 1350X Diameter D: 50 (nom), 51 (max) mm see more »

Overall Length C: 62.75 (nom), 65.4 (max) mm Full product code: 928191205331 Full product name: MASTERColour CDM-Rm Mini 20W/830 GX10 MR16 40D Order code: 928191205331 Order product name: CDM-Rm Mini 20W/830 GX10 MR16 40D Packing configuration: 12 Pieces per pack: 1 Bar code on outerbox - EAN3: 8718291203049 Bar code on pack - EAN1: 8718291203032 Packs per outerbox: 12 Logistic code(s) - 12NC: 928191205331 Net weight per piece: 0.047 kg Warm-up Time to 60% Light Outp: 120 s Beam Angle: 40 D Luminous Intensity: 2100 cd Luminous flux in 90° cone: 950 Lm Lamp Wattage: 20 W Operating Position: any [Any or Universal (U)] Beam Angle Technical: 27 (min), 36 (nom), 45 (max) D Color Rendering Index: 81 (min), 84 (nom) Ra8 Overall Length Rim C1: 60.9 (max) mm ILCOS code: MRS/UB-20/830-H-GX10-51/54.5/40 Life to 50% failures: 15000 hr Color Temperature Technical: 3000 K Mercury (Hg) Content: 3.5 mg Chromaticity Coordinate X: 0.440 - Chromaticity Coordinate Y: 0.400 - Lamp Wattage EL 25°C, Rated: 20.0 W Lamp Voltage: 93 V Damage Factor D/fc: 0.4 (max) - Life to 20% failures: 12000 hr Life to 5% failures: 9000 hr System Power EL: 23.5 W Ignition Time: 30 (max) s Lamp Current EL: 0.215 A Re-ignition Time [min]: 15 (max) min Run-up time 90%: 3 (max) min Reference Length A: 59 (max) mm Life to 10% failures: 10000 hr Design Mean Lumens EL: 850 Lm PET (NIOSH): 8 (min) h500lx Lamp Wattage EL: 20 W Forward Luminous Output: 945 (min), 1050 (nom) Lm Forward Lum Maintenance 2000h: 92 % Forward Luminous Efficacy: 53 Lm/W Forward Lum Maintenance 4000h: 85 % Forward Lum Maintenance 8000h: 78 % Forward Lum Maintenance 12000h: 75 % Forward Lum Maintenance 15000h: 70 % Reflector Neck Temperature: 215 (max) C « hide more

€ 46,19 € 46,19 ex. VAT

Description / FAQ Warranty

The new Philips MASTERColour CDM-R mini brings trusted MASTERColour quality to 50mm reflector lamps with the superior output and colour stability to create the right atmosphere to match your customers' retail brand and positioning. The easy way to reflect more sparkle.

Features

Miniatuzied 50mm CDM reflector lamp

High beam intensity

Long lamp lifetime compared to halogen lamps

Twist and lock system

Applications

Miniaturized crisp white light system for superior accent and general lighting in shops

If you buy goods in partial package that is not currently available in our store (available on request), we reserve the rights to charge additional increments of 5 EUR ex. VAT.
