Metal Halide Lamp POWERSTAR HQI-TS EXCELLENCE Metal Halide Lamps RX7s / RX7s-24

Price € 15,05 € 15,05 ex. VAT

See variants (6)

Ignition voltage 3.6 / 5.0 kVp
UV protection Yes
Rated lamp survival factor at 2,000 h 0.95
Rated lamp survival factor at 4,000 h 0.90
Rated lamp survival factor at 6,000 h 0.85
Rated lamp survival factor at 8,000 h 0.80
Rated lamp survival factor at 12,000 h 0.50
Lifespan B50 12000 h
Design / version Clear
Dimmable No
Burning position p45
Enclosed luminaire required Yes
▼ see full specification ▼

Ask for product Description / FAQ / Warranty

Score

rate product

Select your product from the 6

HQI-TS 150 W/D

Karta produktu PDF

Product code: 56363 Construction wattage [PICOS]: 150.00 W Nominal voltage: 100 V Nominal wattage: 150.00 W Color temperature: 5450 K Rated luminous flux: 13000 lm Diameter: 23.0 mm Length: 135.0 mm Base (standard designation): RX7s-24 Energy efficiency class: A+ Color rendering index Ra: 81 see more »

Lamp mercury content: 12.1 mg Energy consumption: 165 kWh/1000h ILCOS: MD/UB-150/856-H/E/SL-RX7s=24-23/135/H Product weight: 22.00 g Light center length (LCL): 66.0 mm Light color: 860 Rated LLMF at 4,000 h: 0.84 Rated LLMF at 6,000 h: 0.77 Rated LLMF at 8,000 h: 0.74 Rated LLMF at 12,000 h: 0.70 Rated lamp efficacy (standard condition): 86 lm/W Rated LLMF at 2,000 h: 0.86 Lamp current: 1.80000 A PFC capacitor at 50 Hz: 20 µF Maximum permitted outer bulb temperature: 450 °C « hide more

€ 15,05 € 15,05 ex. VAT

HQI-TS 150 W/NDL

Karta produktu PDF

Product code: 56364 Construction wattage [PICOS]: 150.00 W Nominal voltage: 95 V Nominal wattage: 150.00 W Color temperature: 4200 K Rated luminous flux: 12500 lm Diameter: 23.0 mm Length: 135.0 mm Base (standard designation): RX7s-24 Energy efficiency class: A Color rendering index Ra: 80 see more »

Lamp mercury content: 12.3 mg Energy consumption: 165 kWh/1000h ILCOS: MD/UB-150/842-H/E/SL-RX7s=24-23/135/H Product weight: 22.00 g Light center length (LCL): 66.0 mm Light color: 842 Rated LLMF at 4,000 h: 0.84 Rated LLMF at 6,000 h: 0.80 Rated LLMF at 8,000 h: 0.77 Rated LLMF at 12,000 h: 0.73 Rated lamp efficacy (standard condition): 83 lm/W Rated LLMF at 2,000 h: 0.86 Lamp current: 1.80000 A PFC capacitor at 50 Hz: 20 µF Maximum permitted outer bulb temperature: 450 °C « hide more

€ 15,05 € 15,05 ex. VAT

HQI-TS 150 W/WDL

Karta produktu PDF

Product code: 56365 Construction wattage [PICOS]: 150.00 W Nominal voltage: 93 V Nominal wattage: 150.00 W Color temperature: 3200 K Rated luminous flux: 12000 lm Diameter: 23.0 mm Length: 135.0 mm Base (standard designation): RX7s-24 Energy efficiency class: A Color rendering index Ra: 70 see more »

Lamp mercury content: 16.7 mg Energy consumption: 165 kWh/1000h ILCOS: MD/UB-150/730-H/E/SL-RX7s=24-23/135/H Product weight: 22.00 g Light center length (LCL): 66.0 mm Light color: 730 Rated LLMF at 4,000 h: 0.75 Rated LLMF at 6,000 h: 0.67 Rated LLMF at 8,000 h: 0.60 Rated LLMF at 12,000 h: 0.50 Rated lamp efficacy (standard condition): 80 lm/W Rated LLMF at 2,000 h: 0.79 Lamp current: 1.80000 A PFC capacitor at 50 Hz: 20 µF Maximum permitted outer bulb temperature: 500 °C « hide more

€ 15,05 € 15,05 ex. VAT

HQI-TS 70 W/D

Karta produktu PDF

Product code: 56366 Construction wattage [PICOS]: 78.00 W Nominal voltage: 92 V Nominal wattage: 70.00 W Color temperature: 5350 K Rated luminous flux: 6200 lm Diameter: 19.0 mm Length: 117.0 mm Base (standard designation): RX7s Energy efficiency class: A Color rendering index Ra: 75 see more »

Lamp mercury content: 9.9 mg Energy consumption: 86 kWh/1000h ILCOS: MD/UB-70/856-H/E/SL-RX7s-19/117/H Product weight: 17.00 g Light center length (LCL): 57.0 mm Light color: 760 Rated LLMF at 4,000 h: 0.93 Rated LLMF at 6,000 h: 0.85 Rated LLMF at 8,000 h: 0.82 Rated LLMF at 12,000 h: 0.75 Rated lamp efficacy (standard condition): 75 lm/W Rated LLMF at 2,000 h: 0.95 Lamp current: 0.95000 A PFC capacitor at 50 Hz: 12 µF Maximum permitted outer bulb temperature: 500 °C « hide more

€ 15,05 € 15,05 ex. VAT

HQI-TS 70 W/NDL

Karta produktu PDF

Product code: 56367 Construction wattage [PICOS]: 78.00 W Nominal voltage: 93 V Nominal wattage: 70.00 W Color temperature: 4200 K Rated luminous flux: 6500 lm Diameter: 19.0 mm Length: 117.0 mm Base (standard designation): RX7s Energy efficiency class: A Color rendering index Ra: 78 see more »

Lamp mercury content: 10.6 mg Energy consumption: 86 kWh/1000h ILCOS: MD/UB-70/842-H/E/SL-RX7s-19/117/H Product weight: 17.00 g Light center length (LCL): 57.0 mm Light color: 742 Rated LLMF at 4,000 h: 0.90 Rated LLMF at 6,000 h: 0.85 Rated LLMF at 8,000 h: 0.78 Rated LLMF at 12,000 h: 0.73 Rated lamp efficacy (standard condition): 83 lm/W Rated LLMF at 2,000 h: 0.92 Lamp current: 0.95000 A PFC capacitor at 50 Hz: 12 µF Maximum permitted outer bulb temperature: 500 °C « hide more

€ 15,05 € 15,05 ex. VAT

HQI-TS 70 W/WDL

Karta produktu PDF

Product code: 56894 Nominal voltage: 98 V Nominal wattage: 70.00 W Color temperature: 3300 K Rated luminous flux: 5925 lm Diameter: 19.0 mm Length: 117.0 mm Base (standard designation): RX7s Dimmable: No Energy efficiency class: A Color rendering index Ra: 67 see more »

Lamp mercury content: 12.6 mg Energy consumption: 86 kWh/1000h ILCOS: MD/UB-70/730-H/E/SL-RX7s-19/117/H Product weight: 15.00 g Design / version: Clear Light center length (LCL): 57.0 mm Burning position: p45 Light color: 630 Rated LLMF at 4,000 h: 0.64 Rated LLMF at 6,000 h: 0.56 Rated LLMF at 8,000 h: 0.50 Rated lamp survival factor at 2,000 h: 0.95 Rated lamp survival factor at 4,000 h: 0.90 Rated lamp survival factor at 6,000 h: 0.85 Rated lamp survival factor at 8,000 h: 0.80 Rated LLMF at 12,000 h: 0.45 Rated lamp survival factor at 12,000 h: 0.50 Rated lamp efficacy (standard condition): 76 lm/W Rated LLMF at 2,000 h: 0.68 Lamp current: 0.95000 A PFC capacitor at 50 Hz: 12 µF Ignition voltage: 3.6 / 5.0 kVp UV protection: Yes Maximum permitted outer bulb temperature: 500 °C Maximum permitted pinch temperature: 350 °C Lifespan B50: 12000 h Enclosed luminaire required: Yes Hot restart: Yes Rated wattage: 78.00 W « hide more

€ 15,05 € 15,05 ex. VAT

Description / FAQ Warranty

Electrical data
Ignition voltage	3.6 / 5.0 kVp
Photometrical data
UV protection	Yes
Lifespan
Rated lamp survival factor at 2,000 h	0.95
Rated lamp survival factor at 4,000 h	0.90
Rated lamp survival factor at 6,000 h	0.85
Rated lamp survival factor at 8,000 h	0.80
Rated lamp survival factor at 12,000 h	0.50
Lifespan B50	12000 h
Additional product data
Design / version	Clear
Capabilities
Dimmable	No
Burning position	p45
Enclosed luminaire required	Yes
Hot restart	Yes
Temperatures
Maximum permitted pinch temperature	350 °C

Product benefits

High efficiency
Uniform distribution of light
Good to excellent color rendering
Long life time
Hot restrike capable
UV values significantly below the maximum permitted thresholds to IEC 61167 thanks to UV filter

Areas of application

Shop interiors, shop windows
Shopping arcades
Foyers, reception areas
Buildings, monuments, bridges
Museums, exhibitions
Exhibition halls and trade fairs
Pedestrian zones, public squares
Parks and gardens
Approved only for use in enclosed luminaires
Outdoor applications only in suitable luminaires

Product features

POWERSTAR quartz technology
Light colors: warm white (WDL), neutral white (NDL), daylight (D), cool daylight (CD)
Average lifetime: 12,000 hours

System guarantee
For the vast majority of our lamps we are offering an extended system guarantee in conjunction with OSRAM POWERTRONIC control gear.
